Digital Water Level Recorder (Radar type)
125000.0 INR/Piece
Product Details:
- Humidity 0 to 100% RH (non-condensing)
- Product Type Digital Water Level Recorder
- Resolution 1 mm
- Power Supply 12V DC / Solar powered
- Application Water resource management, canal and river monitoring, dam water level measurement
- Temperature -20C to +60C
- Operating Voltage 10-30V DC
- Click to View more
X
Digital Water Level Recorder (Radar type) Price And Quantity
- 1 Piece
- 125000.0 INR/Piece
Digital Water Level Recorder (Radar type) Product Specifications
- RS-485/MODBUS, 4-20mA output
- G 112 (Standard radar port)
- 12 Volt Dc Volt (v)
- Automatic
- 0-30 meters (customizable)
- Mild Steel
- Non-contact measurement, maintenance-free, IP68 enclosure, lightning protection, SD card data logging, wireless telemetry
- Digital Water Level Recorder (Radar Type)
- Automatic
- Threaded/Flange mount
- 30 meters
- Digital touch interface
- LCD Digital Display
- Water Level Recorders
- 2 mm
- < 2 seconds
- 3 kg (approx.)
- Water resource management, canal and river monitoring, dam water level measurement
- 24-26 GHz (Radar Frequency)
- -20C to +60C
- 10-30V DC
- 1 mm
- 0 to 100% RH (non-condensing)
- Digital Water Level Recorder
- 12V DC / Solar powered
- Remote (OTA) supported
- Above water surface, easy to install
- CE Certified, conforms to international standards
- Programmable (from 1 min to 24 hours)
- Optional inbuilt rechargeable lithium battery
- CSV, MODBUS RTU
- GPRS/SMS/Internet compatible
- Lightning/surge/short circuit protection
- Up to 2 years (SD card)
- Integrated Radar Antenna
- Aluminum/Polycarbonate with IP68 rating
- Configurable high/low water level alarm outputs
Digital Water Level Recorder (Radar type) Trade Information
- Cash in Advance (CID)
- 10 Piece Per Month
- 5-7 Days
- All India
Product Description
Virtual make Automatic Water Level Recorder (Radar type) reflect state of the art in micro controller based instrumentation design. The Radar Level sensor can be attached with this IP65 data logger for the collection of real time data automatically. It comes with facility to transport Data from Data Logger to a P.C. through various modes (As per Customer requirement). 16x2 LCD alphanumeric display and 4x2 membrane keypad is provided at front panel of data logger for programming data logger and monitoring sensor reading at site without the help of computer. Comes with different ranges for Liquid: 8, 15, 35, 70 & 120 meters. Data file is saved in Microsofts Excel. This instrument is used for continuous level measurement of liquids or bulk solids. Typical applications are the measurement of liquids in storage tanks or open basins.Advanced Radar-Based Measurement Technology
Utilizing integrated radar antenna technology operating at 24-26 GHz, this recorder delivers exceptional water level accuracy (2 mm) with a high resolution of 1 mm. The non-contact, maintenance-free design guarantees consistent operation without direct exposure to water, minimizing maintenance needs and ensuring long-term durability.
Robust Data Storage and Transmission Features
Users benefit from programmable data logging intervals (1 minute to 24 hours) stored on a built-in SD card capable of holding up to two years of records. Data can be easily retrieved locally or transmitted remotely via GPRS, SMS, or the internet, ensuring timely updates for efficient water resource management.
User-Friendly Installation and Operation
The recorder is designed for above-water installation using threaded or flange mounts, making setup straightforward for new and existing infrastructure. Its digital touch interface and automatic operation ensure ease of use, while remote (OTA) firmware updates further streamline device maintenance and enhancements.
FAQ's of Digital Water Level Recorder (Radar type):
Q: How is the Digital Water Level Recorder (Radar Type) installed above the water surface?
A: Installation is straightforward using either threaded or flange mounting options. The device mounts securely above the water surface, enabling non-contact level measurement to reduce maintenance and ensure reliable performance in diverse sites.Q: What is the typical process for configuring data logging and alarm intervals?
A: Users can easily program data storage intervals-from 1 minute to 24 hours-via the device's digital touch interface. Alarm outputs for high or low water levels are also configurable, allowing users to set thresholds that best meet their operational needs.Q: Where can this water level recorder be effectively used?
A: This device is ideal for water resource management, including canal and river monitoring, dam water level measurement, and various other applications where real-time, accurate water level data is crucial. Its robust construction and wide operating range suit challenging environments.Q: What are the benefits of choosing a radar-type level recorder over traditional methods?
A: Radar technology provides non-contact measurement, eliminating the risk of fouling or corrosion and minimizing maintenance. It ensures precise readings, rapid response times (less than 2 seconds), and high reliability even in extreme weather conditions.Q: How is remote data access and firmware updating managed?
A: The recorder supports wireless data transmission via GPRS/SMS/Internet, allowing remote access to logged data. Firmware updates are conveniently delivered over-the-air (OTA), keeping the device current without the need for on-site servicing.Q: What output formats and interfaces are available for data integration?
A: Data can be exported in CSV and MODBUS RTU formats through interfaces like RS-485 and 4-20mA output, providing versatile integration possibilities for various industrial and monitoring systems.Tell us about your requirement
